DC battery connectors complete a circuit by connecting electrical components to their power source. For consumer electronics, connectors usually refer to the connection where the product "plugs" into the battery, or more commonly, to the power source in the wall. Some types of electrical connectors carry both power and data, but DC battery connectors have a more specialized purpose: they allow electronic devices to operate.
Here is the content:
Basic concepts of power connectors
Power connector construction
hardware components of a power connector
The variety of DC power line connectors on the market reflects their many differences in construction, orientation, and purpose. Some connectors can resist physical damage caused by water, shock, or vibration; others can only tolerate a limited number of connections and disconnections before they may fail. We distinguish power connectors by duration of connection (temporary or permanent), location of the conductive interface (male or female), type of current (alternating or direct) and method of assembly and disassembly.
For a DC power line connector to perform its function correctly, it must have the correct pin arrangement. The pin arrangement is the connection arrangement that each connector can make within the circuit. Each wire is connected to the corresponding contact or pin in the connected part. The wires may have different uses and characteristics. Connector manufacturers use several different methods to make these wire connections, such as 1. soldering. 2. piercing or moving the insulation around the contacts. 3. winding the wire. The selection of the proper connection method depends on the termination of the connector. Terminating exposed pins is just enough to complete a circuit, but not enough to create a dangerous connection that is easily damaged by normal use or maybe accidentally disconnected.
Some of the basic hardware components of DC power line connectors include jacks, blades, needles, receptacles, and plugs.
Jack: A female connector that receives a pin or blade to complete a circuit.
Blade: A flat, conductive metal piece that fits inside the blade socket to complete the circuit.
Pin: A male conductive cylinder that is mounted in a jack as part of a connection.
Receptacle: A socket or connection receptacle, usually the least mobile part of a connector.
Plug: A terminal that may contain multiple jacks, pins, or inserts. The plug is inserted into the receptacle.
The quality of the DC connector is also very important. The above is of the DC connector "concept", "structure", keying and polarization, and basic hardware components explained. Our company's goal is to respond to market demand by continuing to provide new products, adhere to the "integrity-based, quality to win" business philosophy, pursuing the "quality first, customer first, quality service, and abide by the contract" business policy. We are dedicated to the majority of new and old customers. And dedicated to providing quality products and perfect service to our old and new customers, and maintaining our leading position in the industry.
